- Support high resolutions up to 4K x 2K@60Hz, including 480i/p, 576i/p, 720i/p, 1080i, 1080p, 2160p.
- Supports 12-bit Deep Full HD, Full 3D and 4K x 2K video.
- Supports Standard Audio, DSD Audio and HD (HBR) Audio.
- Extend the transmission distance and improve transmission signal.
- Support hot plug-and-play.
- LED indicate signal and power mode.
- Power supply (please refer to technical parameter).
| Return Period | 15 Days |
| Defective Exchange Period | 1 Year |
| Return Period | 15 Days |
| Defective Exchange Period | 1 Year |
| Dimension (L x W x H) | 110x60x20 mm |
| HDMI resolution | 24/50/60fps/480i/480p/576i/576p/720p/1080i/1080p/2160p |
| HDMI Version | HDMI 2.0, HDCP 2.2 |
| Input cable distance | ≤15m AWG26 HDMI standard cable |
| Input/Output DDC signal | 5Volts p-p (TTL) |
| Input/Output TMDS signal | 0.5~1.5Volts p-p(TTL) |
| Manufacturer Part # | HY-SP50102-A-H |
| Max bandwidth | 600MHz |
| Max baud rate | 18.0Gbps |
| Max working current | 800mA |
| Number of Ports | 2 |
| Operating Temperature range | -15 to +55 C |
| Output cable distance | ≤20m AWG26 HDMI standard cable |
| Ports | HDMI Female |
| Power adapter format Input | AC100V-240V (50/60Hz) ; Output: DC 5V/1A |
| Supports audio format | DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR) |
| Supports video color format | 24bit/deep color 30bit, 36bit, 48bit |
| Weight | 105g |
| Dimension (L x W x H) | 110x60x20 mm |
| HDMI resolution | 24/50/60fps/480i/480p/576i/576p/720p/1080i/1080p/2160p |
| HDMI Version | HDMI 2.0, HDCP 2.2 |
| Input cable distance | ≤15m AWG26 HDMI standard cable |
| Input/Output DDC signal | 5Volts p-p (TTL) |
| Input/Output TMDS signal | 0.5~1.5Volts p-p(TTL) |
| Manufacturer Part # | HY-SP50102-A-H |
| Max bandwidth | 600MHz |
| Max baud rate | 18.0Gbps |
| Max working current | 800mA |
| Number of Ports | 2 |
| Operating Temperature range | -15 to +55 C |
| Output cable distance | ≤20m AWG26 HDMI standard cable |
| Ports | HDMI Female |
| Power adapter format Input | AC100V-240V (50/60Hz) ; Output: DC 5V/1A |
| Supports audio format | DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD HD(HBR) |
| Supports video color format | 24bit/deep color 30bit, 36bit, 48bit |
| Weight | 105g |
