Brand |
ZEBRA |
|
Manufacturer Part Number |
LS2208-SR20001R-NA |
|
Ambient Light Immunity: |
Immune to direct exposure of normal office and factory lighting conditions, as well as direct exposure to sunlight |
|
Color: |
Cash Register White or Twilight Black |
|
Current: |
130 mA typical, 175 mA max |
|
Decode Capability: |
UPC/EAN, UPC/EAN with Supplementals, UCC/EAN 128, Code 39, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, IATA, RSS variants, Chinese 2 of 5 |
|
Dimensions: |
6 in. H x 2.5 in. W x 3.34 in. D 15.2 cm H x 6.3 cm W x 8.4 cm |
|
Drop Specifications: |
Unit functions normally after repeated 5 ft./1.5 m drops to concrete |
|
Electrical Safety: |
Certified to UL1950, CSA C22.2 No. 950, EN60950/IEC950 |
|
Electrostatic Discharge: |
Conforms to 15 kV air discharge and 8 kV of contact discharge |
|
EMI/RFI: |
FCC Part 15 Class B, ICES-003 Class B, European Union EMC Directive, Australian SMA, Taiwan EMC, Japan VCCI/MITI/Dentori. |
|
Hands-Free Intellistand |
20-61019-01 or 20-61019-02 |
|
Humidity: |
5% to 95% relative humidity, noncondensing |
|
Interfaces Supported: |
RS232, Keyboard Wedge, Wand, IBM 468X/9X, USB, Synapse and Undecoded |
|
Laser Safety: |
CDRH Class II, IEC Class 2 |
|
Light Source: |
650 nm visible laser diode |
|
Nominal Working Distance: |
From contact to 17 in./43 cm on 100% U.P.C./EAN symbols |
|
Operating Temperature: |
32° to 122° F/0° to 50° C |
|
Pitch: 2 |
2 +/- 65 degrees |
|
Power Sources: |
Host power or external power supply |
|
Print Contrast: |
20% minimum reflective difference |
|
Roll (Tilt): 1 |
1 +/- 30 degrees |
|
Scan Rate: |
100 scans per second typical |
|
Scanner Type: |
Bi-directional |
|
Skew (Yaw): 3 |
3 +/- 60 degrees |
|
Stand-by Current (USB suspend current) |
>500µA |
|
Storage Temperature: |
-40° to 158° F/-40° to 70° C |
|
Weight: |
5.15 oz./146 gm |
