Box Dimensions (WxHxD) |
13.4 x 6.1 x 14.0 |
|
Common Mode Rejection Ratio |
Better than -70 dB @ 1 kHz |
|
Crosstalk / Attenuation |
Main Mix Knob Down: -75 dBu, Channel Alt / Mute Switch Engaged: -85 dBu, Channel Gain Knob Down: -87 dBu (1 kHz relative to 0 dBu, 20 Hz to 20 kHz bandwidth, line in, 1/4" main out, gain at unity) |
|
Dimensions (H x W x D) |
10.7 x 11.9 x 3.0" (273.0 x 303.0 x 75.0 mm) |
|
Equalizer |
High Shelving: +/-15 dB @ 12 kHz, Mid Peaking: +/-15 dB @ 2.5 kHz, Low Shelving: +/-15 dB @ 80 Hz |
|
Equivalent Input Noise |
150 Ohm Termination: -128.5 dBu, 20 Hz to 20 kHz, Microphone input to insert send out, maximum gain |
|
Frequency Response |
Microphone Input to Main Output (Gain @ Unity): +0, -1 dB, 20 Hz to 50 kHz, +0, -3 dB, 100 kHz |
|
Fuse Rating |
100 to 120 V: 500 mA slo blo, 5 x 20 mm, 220 to 240 V: 250 mA slo blo, 5 x 20 mm |
|
Impedance |
Microphone In: 2.5 kOhm, Channel Insert Return: 2.5 kOhm, All Other Inputs: 10 kOhm or greater, Tape Out: 1.1 kOhm, All Other Outputs: 120 Ohm |
|
Maximum Level |
Microphone In: +22 dBu, Tape In: +16 dBu, All Other Inputs: +22 dBu, Main Mix XLR Out: +28 dBu, All Other Outputs: +22 dBu |
|
Noise |
Main Mix Noise: Main Mix Knob Down, Channel Gain Knobs Down: -100 dBu, Main Mix Knob @ Unity, Channel Gain Knobs Down: -86.5 dBu (90 dB signal to noise ratio, ref +4 dBu), Main Mix Knob @ Unity, Channel Gain Knobs @ Unity: -84.5 dBu (20 Hz to 20 kHz bandwidth, 1/4" main out, channels 1 to 4, gain @ unity, channel EQs flat, all channels assigned to main mix, channels 1 and 3 panned left, 2 and 4 panned right) |
|
Operating Temperature |
32 to 104 F (0 to 40 C) |
|
Power Consumption |
25 W, 100 to 120 VAC, 50 to 60 Hz |
|
Shipping Weight |
10.6 lb |
|
Total Harmonic Distortion (THD) |
Microphone Pre @ Insert: |
|
Weight |
6.5 lb (3.0 kg) |
