Automation Controls |
Touch, Latch, Trim, Write, Read, Off |
|
Channel Controls |
Level, Pan, Solo, Mute, Select, Rec Arm |
|
Console Management |
Show/Hide: Audio Tracks, Inputs, MIDI Tracks, Buses, Outputs, VCAs, FX; Show All |
|
Displays |
16 digital scribble strip displays, time code display, channel meters |
|
Faders |
16 100 mm long-throw, touch-sensitive, motorized faders, Dual-servo motorized drive belt system for fast and quiet operation, Ultra-smooth feel and lightning fast Heavy-duty construction, Resolution: 10-bit, 1,024 steps |
|
General Controls |
Undo/Redo, Arm All, Solo/Mute Clear, Timecode, Track Management, Click On/Off, 4 programmable User buttons, 8 Function buttons, Macro, Parameter Link, Bypass Plug-ins |
|
Input / Output |
1 USB 2.0 port, 1 Footswitch jack for hands-free stop/start |
|
Navigation |
Track Scroll, Channel Banking, Timeline Scroll, Horizontal Zoom, Vertical Zoom, Drop Marker, Next/Prev Marker, Next/Prev Event, Scrub, Nudge |
|
Optional Fader Functionality |
Plug-in Edit, Bus Sends, Pan |
|
Transport |
Play, Stop, Fast Forward, Rewind, Record, Loop, Return to Zero (Functionality varies slightly, depending on the DAW.) |
|
Window View |
Mix, Project, Transport, Undo |
